Description

【Japan Market Only】Chassis pre-installed with high performance brushless motor! Next generation MINI-Z introduces even more durability and power!

Technical Data

＜ Chassis Specification ＞
■Length: 124-133mm （MM Chassis: 125-133mm, RM Chassis: 124-132mm）
■Width: 65-76mm
■Height: 34-35mm
■Wheelbase: 86-106mm（86, 90, 94, 98, 102, 106）
■Tread (F/R): (Wide) 61.5mm / 59mm (Narrow) 56.5mm / 56.5mm (when wheel offset is 0)
■Tire (F/R): 23.5- 25×8.5mm / 25-27×8.5-11mm
■Gear Ratio: 7.3, 6.3, 5.5, 4.9:1
■Weight: 135g
■Motor: Team Orion ECO Tune VE (5600Kv)

＜ New Beetle Turbo S Specification ＞
■Length: 144.5mm
■Widht: 70.0mm
■Height: 54.0mm
■Chassis Type: MR-03N-HM
■Wheelbase: 90.0mm (M)
■Tread (F/R): 56.5mm / 56.5mm
■Tire (F/R): Φ25.0mm x 8.5mm / Φ25.0mm x 8.5mm
■Weight: 164g

Kit Content

＜ Kit Contents ＞
●Factory assembled MR-03W-MM chassis with Team Orion ECO Tune brushless motor
●RA-27 brushless ESC/receiver PCB unit with ICS connector
●Front lower & upper plates and stearing tie rod for narrow tread specification (included)
●Front suspention spacers for adjustments
●7T, 8T & 9T pinion gears
●Wheel wrench
●Pinion ger remover
●Pairing stick
●Spare wheel nut

Requirement to Run

＜ Required for Operation ＞
●Perfex KT-18 transmitter or EX-5UR trnasmitter(No.82011)
●Batteries for chassis: AAA-sized alkaline batteries x 4 or Ni-MH batteries x 4
●Batteries for transmitte:r (KT-18) AAA-sized alkaline batteries x 4 (EX-5UR) AA-sized alkaline batteries x 8
