Description
Major upgrade to receiver circuit board! New 2nd generation Sports chassis!
From its launch in 2013 the MINI-Z Racer Sports MR-03 Readyset made it easy for a wider group of racers to enjoy the precision control of its MR-03 base chassis that built its formidable reputation on the MINI-Z racing scene. This next generation upgrade remains faithful to this original concept. One major upgrade is the advanced gyro unit (MZW431) that can be mounted on the Mini-Z AWD Sports, is also able to be mounted on the MINI-Z Racer Sports 2 MR-03. The gyro’s sensitivity can be adjusted through a volume control installed on the chassis. Redesign of the steering control setup to accommodate the gyro has resulted in higher degree of steering precision compared to the previous model. In addition, when used in conjunction with the KT-432PT transmitter (sold separately), the gyro sensitivity can be adjusted directly from the transmitter, regardless of the volume setting on the chassis. The same applies to steering force settings, which can also be adjusted from the KT-432PT transmitter. With these two functions, precise setting can be achieved to optimize steering feel to your individual driving style. The MR-03 chassis lays the foundation for the new racing experience of the MINI-Z Sports 2!
・Factory assembled chassis ・Pre-painted factory assembled plastic body finished with markings ・2.4Ghz transmitter Perfex KT-19 ・Parts set for changing front tread ・Front suspension spacer for adjustment ・6T, 7T, 8T, 9T pinion gears ・Wheel wrench ・Pinion tools ・Spare wheel nut ・Tires and wheels includedMR-03 chassis is equipped with a special Sports 2 circuit board. Combines high performance and compatibility with all body styles.
Features the newly designed FHS 2.4GHz Perfex KT-19 transmitter. Equipped with trim to adjust the optional light unit.
In addition to the light unit, a special gyro unit (MZW431) can also be installed. Gyro sensitivity can be adjusted by turning the volume dial.
Can be set to either narrow or wide tread by replacing the front lower and upper plates and steering tie rod. Of course the wheelbase can still be adjusted to suit certain car types. *Change wheelbase requires optional parts.
Technical Data
■Length
124-133mm (MM Chassis:125-133mm, RM Chassis:124-132mm)
■Width
65-76mm
■Height
34-35mm
■Wheelbase
86-106mm (86, 90, 94, 98, 102, 106)
■Tread (F/R)
(Wide)61.5mm / 59mm (Narrow)56.5mm / 56.5mm [when wheel offset is 0]
■Tire(F/R)
23.5-25×8.5mm / 25-27×8.5-11mm
■Gear Ratio
7.3, 6.3, 5.5, 4.9:1
■Weight
135g approx.
■Motor
130-Class
Kit Content
・Pre-painted factory assembled plastic body finished with markings
・2.4Ghz transmitter Perfex KT-19
・Parts set for changing front tread
・Front suspension spacer for adjustment
・6T, 7T, 8T, 9T pinion gears
・Wheel wrench
・Pinion tools
・Spare wheel nut
・Tires and wheels included
Requirement to Run
・AAA x 4 alkaline batteries for transmitter
