Front suspension optimizes camber angle in concert with stroke. Thoroughly low center of gravity design. Powerful drive train. No detailed overlooked to create the strongest MINI-Z Racer MR-03 chassis. Exceptional performance is now available in a Readyset for everyone to enjoy! Requires no frequency band selection and up to 40 cars can be run together at the same time. Also compatible with all MINI-Z Racer scale bodies. With the user-friendly features of a Sports version, the dynamic racing performance from its MR-03 base becomes immediately obvious as soon as you drive. This is the true essence of the MINI-Z. The chassis features a connector for the installation of a special light unit (Not Included) that lights up/flashes headlights and taillights in response to throttle and brake control. This is no cheap gimmick but scale realism in its most complete sense. MINI-Z Racer Sports MR-03 Readyset brings performance and style within easy reach for everyone to experience and enjoy!
●Features Perfex KT-19 transmitter. Steering volume adjustment possible.
●Factory assembled with quality finish suitable for interior display.
●All MINI-Z Racer bodies can be installed. *Requires compatible motor case and diff gear assembly.
●Features unique front suspension (VCS) that delivers optimum camber change in concert with suspension stroke.
●Spring stopper can be detached with just two screws for easy replacement of coil spring on front suspension.
●A huge variety of parts for MR-03 chassis can be installed.
●Note) Optional gyro unit and ICS cannot be used.
●Also, this model is specially designed for the KT-19 transmitter so there is no compatibility with the former KT-18 transmitter/EX-5UR ASF transmitter (No.82011).
- TECHNICAL DATA
■Length: 124-133mm(MM Chassis:125-133mm,RM Chassis:124-132mm)
■Tread (F/R): (Wide)61.5mm / 59mm (Narrow)56.5mm / 56.5mm [when wheel offset is 0]
■Gear Ratio: 7.3,6.3,5.5,4.9:1
■Weight: 135g approx.
- KIT CONTENTS
＜ Readyset Contents ＞
●Factory assembled chassis
●Pre-painted factory assembled plastic body finished with markings
●2.4Ghz transmitter Perfex KT-19
●Parts set for changing front tread
●Front suspension spacer for adjustment
●6T, 7T, 8T, 9T pinion gears
●Spare wheel nut
●Tires and wheels included
- REQUIRED FOR OPERATION
＜ Required for Operation ＞
●4 x AAA size alkaline batteries or NiMH x 4 for chassis
●AAA x 4 alkaline batteries for transmitter
